Thrust Bearing Engineering Specifications (inches)
** Click on Desired Thrust Bearing for Detailed Technical Information**
|
||||||||||
|
THRUST WASHER
|
BALL
|
BEARING
|
||||||||
|
Bearing
No.
|
A
I.D. |
Tolerance
|
B
O.D. |
Tolerance
|
D
Thick |
Tolerance
|
Qty.
Per |
F
Size |
C
Circle |
E
Height |
|
1/8
3/16 1/4 5/16 |
0.128-0.133
0.191-0.195 0.253-0.258 0.316-0.321 |
7/16
1/2 9/16 5/8 |
0.430-0.437
0.492-0.499 0.555-0.562 0.617-0.624 |
0.050
|
0.048-0.052
|
6
7 8 9 |
0.0938
|
0.281
0.344 0.406 0.469 |
0.190-0.198
|
|
|
3/8
7/16 1/2 9/16 |
0.378-0.383
0.441-0.446 0.503-0.508 0.566-0.571 |
13/16
7/8 15/16 1 |
0.805-0.812
0.867-0.874 0.930-0.937 0.992-0.999 |
0.062
|
0.060-0.064
|
6
7 8 9 |
0.1250
|
0.594
0.656 0.719 0.781 |
0.245-0.253
|
|
|
5/8
11/16 3/4 13/16 7/8 |
0.628-0.635
0.691-0.698 0.753-0.760 0.816-0.823 0.878-0.885 |
1-1/8
1-3/16 1/1/4 1-5/16 1-3/8 |
1.115-1.124
1.178-1.187 1.240-1.249 1.303-1.312 1.365-1.374 |
0.093
|
0.090-0.096
|
6
7 8 9 10 |
0.1563
|
0.875
0.938 1.000 1.063 1.125 |
0.336-0.348
|
|
|
15/16
1 1-1/8 1-1/4 1-1/2 |
0.941-0.950
1.003-1.012 1.128-1.137 1.253-1.262 1.503-1.512 |
1-9/16
1-5/8 1-3/4 1-7/8 2-1/8 |
1.551-1.562
1.613-1.624 1.738-1.749 1.863-1.874 2.113-2.124 |
0.125
|
0.120-0.130
|
9
10 12 14 14 |
0.1875
|
1.250
1.313 1.438 1.563 1.813 |
0.428-0.448
|
|
|
2
2.5
3 3.5 |
2.000-2.020
2.500-2.520 3.000-3.020 3.500-3.520 |
3
3.5 4 4.5 |
2.980-3.000
3.480-3.500 3.980-4.000 4.480-4.500 |
0.188
|
0.183-0.193
|
12
14 15 15 |
0.250
0.250 0.250 0.250 |
2.500
3.000 3.500 4.000 |
0.616-0.636
|
|
|
4
4.5
5 |
4.000-4.020
4.500-4.520 5.000-5.020 |
5
5.5 6 |
4.980-5.000
5.480-5.500 5.980-6.000 |
0.188
|
0.183-0.193
|
12
12 15 |
0.313
0.313 0.313 |
4.500
5.000 5.500 |
0.679-0.699
|
|
|
Thrust Bearing Load Ratings (in Pounds)
Carbon Steel Bearings & Thrust Washers ** Click on Desired Thrust Bearing for Detailed Technical Information**
|
||||||||
|
Bearing
No.
|
RPM
15 |
RPM
100 |
RPM
450 |
RPM
900 |
RPM
1200 |
RPM
1800 |
RPM
3600 |
RPM
5000 |
|
120
126 131 136 |
63
70 69 72 |
38
40 42 43 |
30
32 34 34 |
27
29 29 31 |
24
25 26 27 |
19
20 21 22 |
17
18 18 19 |
|
|
175
190 201 213 |
93
101 106 113 |
56
61 64 68 |
44
48 51 54 |
40
44 46 49 |
35
38 40 49 |
28
30 32 34 |
25
27 29 30 |
|
|
251
273 293 314 328 |
133
145 155 166 174 |
80
87 94 101 105 |
64
69 74 80 83 |
58
63 68 72 76 |
51
55 59 63 66 |
40
44 47 50 52 |
36
39 42 45 47 |
|
|
384
459 504 545 522 |
204
243 267 289 277 |
123
147 162 175 168 |
98
117 128 139 133 |
89
106 117 125 121 |
77
93 102 110 105 |
61
73 81 87 84 |
55
66 72 78 75 |
|
|
400
500
500
550
|
212
265
265
291
|
128
160
160
176
|
--
|
--
|
--
|
--
|
--
|
|
|
575
575
650
|
305
305
344
|
184
208
208
|
--
|
--
|
--
|
--
|
--
|
|
|
Carbon Steel Thrust Bearing Technical Data
|
|
|
Washer:
|
CR 1075 steel heat treated to RC 59-61 |
|
Ball Material:
|
S.A.E. 1018 steel with RC 60 minimum |
|
Ball Tolerance:
|
± 0.0001 in. (Grade 100) |
|
Retainer:
|
HS nylon permitting continuous use up to 250º F |
Our Carbon Steel Thrust Bearings combine the time-proven design of a cost-saving, lightweight nylon retainer with the high strength to wear ratio of hardened carbon steel thrust washers.
